Multifunction CCD Rice Color Sorter Machine For Beans/Grain/Wheat/Maize small Rice Sorting Machines
What is a CCD in a camera?
Stands for "Charged Coupled Device." CCDs are sensors used in digital cameras and video cameras to record still and moving images. The CCD captures light and converts it to digital data that is recorded by the camera. For this reason, a CCD is often considered the digital version of film.
1. Rice Color sorter working principle :
Raw materials are put into the machine from its material hopper on the top, vibrated by vibratory feeder and sliding along material chute into the zone of observation in sorting chamber through sensors and background plate. Under the effect of lamps source, CCD sensor receives compound light from materials being sorted. According to the light intensity and color changes, make the system produce output signal and drive solenoid valve(ejector) to work, ejecting the discolor grain to reject chamber and good materials continue to fall into the finished accept chamber
2. Technical Parameters:
WYCS1-64 Rice Color Sorter Parameters
| Output(depend on material impurity rate) | 0.3-0.7t/h |
| Sorting Accuracy(%) depend on sorting times | 99.99% |
| Rejection Rate(Bad:Good) | 30:1 |
| Gross Weight of one chute rice color sorter | 313kg |
| Whole Power(kw) | 0.75kw |
| Machine Demensions(L*W*H) | 780*1527*1543MM |
| Air Pressure(Mpa) | 0.6-0.8 |
| Air Consumption(L/min) | 200-600 |
3. Wenyao color sorter Machine Features:
4. Examples of Color Sorting Examples
Wenyao multifunction color sorter application
Customized color sorter
Can be customized according to customer specific color selection program.
Industrial product color sorter
Used for:Waste Plastics,Plastic pellet,Plastic pieces,Plastic granule,Plastic bottle cap flake,PET bottle scrap,ABS
plastic flake,PP plastic scrap,Recycled plastic,Quartz stone,Quartz sand,Potassium feldspar,Barite,Calcite,Pearl,
Marble and others.
Agriculture products color sorter
Used for:Rice,Wheat,Corn,Soybean,Peanut,Nut,Grain,Cereal,Seeds,Bean,Sunflower seeds,Waltnut,Almond,
Quinoa,Salt,Medlar,Pistachio,Kidney bean,Red bean,Black bean,Green bean,Coffee bean,Fava bean,Mung
bean,Millet,Sorghum,Peeled garlic,Dehydrated garlic,Lotus seed,Sesame,Pinenut kernel,Watermelon seeds,
Cotton seeds,Melon seeds,Buckwheat,Oats,Barley,Cardamon,Pea,Lentil,Cashew nut,Raisin,Jujube,Evaporate vegetables,Sugar,Onion,Potato,Blueberry,Tomato,Mango,Chickpea,Olives,Chili,others.
River&Sea food color sorter
Used for: Dried shrimp, fish, small fish clove and so on.
5. Packing and Delivery:
Our products use professional wooden cases with PE plastic bag.
Package size will depend on each model size.
6. Delivery Detail:
Within 3 - 5 days after received deposit.
7. Our Service:
A: For software:We have installed WIFI remote control system on machine,Once machine arrived in your local
we will connect with machine touch screen provide technical assistance from Chinese factory.
B: For hardware:We will supply you the spare parts ship together with machine,In case you face hardware problems,
we will guide you how to repair by live videos.
